The Nissan GT-R's VR38DETT engine is nothing short of legendary. When Nissan released the R35 GT-R in 2007, they didn't just build a fast car - they engineered a technological masterpiece that redefined what a production vehicle could achieve. The 3.8-liter twin-turbocharged V6 at its heart has become one of the most impressive and tunable engines of the modern era. At Raw Exotics, we've built and tuned numerous VR38s, from mild street cars to 1,500+ HP drag monsters. Today, I'm going to share everything you need to know about this incredible powerplant.
VR38DETT Technical Specifications
Understanding the VR38's engineering is essential to appreciating its capabilities.
Core Engine Architecture
- Displacement: 3,799cc (3.8 liters)
- Configuration: 60-degree V6
- Bore x Stroke: 95.5mm x 88.4mm (3.76" x 3.48")
- Compression Ratio: 9.0:1 (2009-2010), 9.6:1 (2011+)
- Block Material: Aluminum alloy with plasma-sprayed bore coating
- Cylinder Heads: Aluminum with DOHC, 4 valves per cylinder
- Valvetrain: Chain-driven dual overhead cams, sodium-filled exhaust valves
- Lubrication: Dry-sump oil system with dedicated scavenge pumps
Forced Induction System
The VR38's twin-turbo setup is a masterclass in engineering:
- Turbochargers: Twin IHI (Ishikawajima-Harima) ball-bearing turbos
- Compressor wheels: 60mm inducer (varies by year/model)
- Wastegate: Internal wastegates with electronic boost control
- Intercooler: Air-to-air front-mount intercooler
- Boost pressure: 10.8 psi (2009-2010), 13.7 psi (2012+ Premium), 16.5+ psi (NISMO models)
Fuel and Engine Management
- Fuel delivery: Direct injection (GDI) with high-pressure fuel pumps
- Injectors: Bosch piezoelectric direct injectors
- ECU: Nissan proprietary engine control unit
- Ignition: Individual coil-on-plug design
- Throttle: Dual drive-by-wire throttle bodies (one per bank)
Factory Power Output by Year
Nissan continuously improved the VR38 throughout production:
- 2009-2010 (R35 MY09-10): 480 HP / 430 lb-ft (SAE certified 485 HP)
- 2011 (R35 MY11): 530 HP / 448 lb-ft
- 2012-2016 (Premium): 545 HP / 463 lb-ft
- 2015-2022 (NISMO): 600 HP / 481 lb-ft
- 2017-2024 (Premium/Track Edition): 565-600 HP / 467-481 lb-ft
What's remarkable is that many dyno tests show higher wheel horsepower than Nissan's advertised crank numbers, suggesting the VR38 is significantly underrated from the factory.
What Makes the VR38 Special
The VR38DETT isn't just another twin-turbo V6. Several features elevate it to legendary status.
Hand-Built by Master Craftsmen
Each VR38 is hand-assembled by a single Takumi (master craftsman) at Nissan's Yokohama engine plant. The technician's nameplate is affixed to the engine, signifying their personal responsibility for its quality. This attention to detail results in remarkably consistent quality and tight manufacturing tolerances.
Plasma-Sprayed Bore Coating
Rather than traditional cylinder liners, the VR38 uses plasma-sprayed bore coating - a process where molten metal is sprayed onto the cylinder walls at supersonic speeds. This creates an incredibly hard, low-friction surface that's lighter than iron liners while providing superior wear resistance.
Benefits:
- Reduced friction and improved efficiency
- Better heat dissipation
- Weight savings
- Enhanced durability
Dry-Sump Lubrication
Unlike most production cars using wet-sump oiling, the VR38 employs a dry-sump system with external oil tank and dedicated scavenge pumps. This provides:
- Consistent oil pressure during high-G cornering
- Lower center of gravity (engine sits lower without deep oil pan)
- Reduced oil starvation risk
- Better oil cooling and aeration control
Individual Cylinder Ignition Timing
The VR38's advanced ECU can adjust ignition timing individually for each cylinder based on knock sensor feedback. If one cylinder experiences detonation, only that cylinder gets timing retarded rather than pulling timing from all six. This allows the engine to operate closer to its knock limit safely.
Reliability and Common Issues
The VR38 is generally bulletproof when properly maintained, but there are known issues to watch for.
Known Issues and Failure Points
1. Transmission Failures (Not Engine, but Related)
The GR6 dual-clutch transmission is the weak link in the GT-R drivetrain. Stock transmission limits:
- ~600 WHP on stock clutches (hard launches accelerate wear)
- ~800 WHP with upgraded clutches
- Beyond 800 WHP, full transmission builds or sequential swaps needed
2. Turbocharger Failures (Launch Control Abuse)
Excessive use of launch control, particularly on early MY09-10 models, can grenade turbos due to rapid pressure cycling. Later models have more durable turbos, but abuse still takes its toll.
Prevention:
- Limit launch control use
- Regular oil changes with quality synthetic
- Allow proper warm-up and cool-down periods
- Monitor for shaft play or excessive noise
3. Fuel System Limitations (Modified Cars)
Stock fuel system maxes out around 650-700 WHP. Beyond this, you'll need:
- Upgraded high-pressure fuel pumps
- Larger fuel injectors or supplemental port injection
- Potentially E85 conversion for additional fueling capacity
4. Carbon Buildup (Direct Injection)
Like all direct injection engines, the VR38 suffers from intake valve carbon buildup since fuel doesn't wash over valves. Symptoms include rough idle, misfires, and power loss.
Solution: Walnut blasting intake valves every 50,000-70,000 miles
Maintenance Best Practices
Keep your VR38 healthy with proper maintenance:
- Oil changes: Every 3,000-5,000 miles with Nissan Ester Oil or equivalent quality synthetic
- Transmission fluid: Change every 15,000-18,000 miles (more frequently for hard-driven cars)
- Spark plugs: Replace every 30,000-40,000 miles (sooner for modified cars)
- Air filters: Inspect every 10,000 miles, replace as needed
- Intercooler cleaning: Remove bugs and debris to maintain cooling efficiency
- Fuel filter: Replace every 30,000 miles
Tuning the VR38: Software and Bolt-Ons
The VR38 responds incredibly well to tuning, with massive gains possible from ECU calibration alone.
ECU Tuning Options
1. COBB Accessport
- Most popular tuning solution for GT-Rs
- Pre-loaded Stage 1/2 maps available
- Custom tuning capability with pro tuners
- Real-time data logging and monitoring
- Cost: $800-1,000
- Gains: 60-100 HP with bolt-ons and proper tuning
2. EcuTek RaceROM
- Professional tuning platform with extensive features
- Flat-foot shifting, launch control refinement, advanced boost control
- Requires professional tuner
- Excellent for custom builds and flex-fuel setups
- Cost: $600-800 plus tuning
3. UpRev Osiris
- Full ECU tuning suite
- Good for custom modifications
- Smaller tuner network than COBB or EcuTek
- Cost: $500-700 plus tuning
Bolt-On Modifications and Power Gains
Stage 1: Tune, Intake, Exhaust (600-650 WHP)
Parts:
- ECU tune (COBB, EcuTek, or UpRev)
- Performance intake (AMS, Injen, or similar)
- Cat-back or full exhaust (Armytrix, Akrapovic, Titanium)
Results:
- 600-650 WHP / 550-600 lb-ft
- 60-100 HP gain over stock
- Cost: $2,500-4,000
- Reliability: Excellent on stock motor
Stage 2: Downpipes, Intercooler (650-750 WHP)
Add to Stage 1:
- High-flow downpipes (AMS, Agency Power, Greddy)
- Upgraded intercooler (AMS Alpha, ETS, GReddy)
- Boost controller (electronic preferred)
Results:
- 650-750 WHP / 600-700 lb-ft
- Significantly improved intercooler efficiency
- Lower exhaust backpressure and EGT
- Cost: $5,000-8,000 additional
- Reliability: Good on stock motor with conservative tune
Stage 3: Upgraded Turbos (800-1,200 WHP)
Add to Stage 2:
- Upgraded turbochargers (AMS Alpha 6 or 9, ETS G1, Garrett GTX units)
- Fuel system upgrades (pumps, injectors, or port injection)
- Transmission upgrades (clutches minimum, potentially full build)
Results:
- 800-1,200 WHP depending on turbo size and supporting mods
- Alpha 6 turbos: 800-900 WHP
- Alpha 9 turbos: 900-1,100 WHP
- Cost: $12,000-20,000 additional
- Reliability: Requires built motor beyond 850-900 WHP
Building the VR38 for Maximum Power
For serious power, internal modifications become necessary.
Stock Internal Limits
Conservative estimates for stock VR38 internals:
- Safe power level: 800-850 WHP / 700-750 lb-ft
- Aggressive (higher risk): 900-1,000 WHP
- Failure points: Connecting rods (most common), pistons, ring lands
Forged Internal Build
For 1,000+ WHP, forged internals are essential:
Core Components:
- Forged pistons: JE, Wiseco, or CP Carrillo, designed for boost
- Forged connecting rods: Carrillo, Manley, or Oliver billet rods
- Crankshaft: Stock crank is forged and adequate to 1,200+ HP; billet for extreme builds
- Main and head studs: ARP fasteners throughout
- Bearings: Upgraded bearings (ACL, King, or Cosworth)
- Oil pump: Upgraded oil pump gears for higher volume
Cost for complete forged build: $15,000-25,000 (parts, machine work, assembly)
Cylinder Head Work
Stock VR38 heads flow very well, but can be improved:
- CNC porting (30-50 HP gain on high-power builds)
- Upgraded valve springs for higher RPM capability
- Titanium valve retainers (weight reduction)
- Multi-angle valve job
- Cost: $3,000-6,000 per head
Power Levels with Built Motor
- Street build (pump gas): 1,000-1,200 WHP
- E85 build: 1,200-1,500 WHP
- Race gas build: 1,500-2,000 WHP
- All-out drag racing: 2,000+ WHP possible (but at that point you're essentially building a new engine)
The Alpha Packages: A GT-R Tuning Standard
AMS Performance's Alpha packages have become the benchmark for GT-R builds:
Alpha 6: 800-900 WHP, stock block capable, great street manners
Alpha 9: 900-1,100 WHP, stock block limit, track-focused
Alpha 12: 1,100-1,300 WHP, requires built motor, serious performance
Alpha 16/20: 1,300-1,700+ WHP, full race builds, built motor mandatory
These packages include turbos, fuel system, ECU tuning, and all necessary supporting components. They've proven themselves at countless tracks and drag strips worldwide.
E85 Conversion: The Secret Weapon
Converting a GT-R to E85 fuel offers massive benefits:
Advantages of E85
- Effective octane rating of 100-105 (vs. 93 for pump gas)
- Significant cooling effect from high latent heat of vaporization
- Allows more boost and timing than pump gas
- 20-30% more power on same turbo setup
- Reduced knock and detonation risk
E85 Power Gains
- Stock turbos on pump gas: 650 WHP → E85: 750-800 WHP
- Alpha 6 on pump gas: 850 WHP → E85: 950-1,000 WHP
- Significant torque increases throughout RPM range
Required Modifications
- Upgraded fuel system (E85 requires 30-40% more fuel volume)
- Flex-fuel sensor and tuning
- Potentially upgraded injectors or supplemental port injection
- E85-compatible fuel lines and components
Transmission Considerations
The GR6 dual-clutch transmission is sophisticated but has limits.
Stock Transmission Capacity
- Stock clutches: ~600 WHP (varies with driving style)
- Factors: Launch control use, drag racing, track use all accelerate wear
Transmission Upgrades
Stage 1 (600-800 WHP):
- Upgraded clutch packs
- Enhanced TCM tuning
- Cost: $5,000-8,000
Stage 2 (800-1,000 WHP):
- Full clutch upgrade
- Upgraded shafts and gears
- Enhanced cooling
- Cost: $10,000-15,000
Beyond 1,000 WHP:
- Full transmission build with billet components
- Or sequential transmission conversion
- Cost: $15,000-30,000+
Real-World Build Examples
Street GT-R (Daily Driver with Teeth)
- COBB Stage 2 tune
- Intake and exhaust
- Downpipes
- Upgraded intercooler
- Power: 650 WHP
- Cost: $6,000-8,000
- Reliability: Excellent
Street/Track GT-R (Weekend Warrior)
- Alpha 6 turbo kit
- Full exhaust and intercooler
- E85 conversion
- Transmission stage 1 upgrade
- Power: 900 WHP
- Cost: $25,000-35,000
- Reliability: Good with proper maintenance
Dedicated Track/Drag GT-R
- Built motor with forged internals
- Alpha 12 or custom turbo setup
- Full race fuel system
- Built transmission
- Power: 1,200-1,500 WHP
- Cost: $60,000-100,000
- Reliability: Race car (frequent maintenance, not streetable)
Final Thoughts
The Nissan GT-R's VR38DETT engine is a masterpiece of automotive engineering. It combines sophisticated technology, robust construction, and incredible tuning potential into a package that can be daily driven at 600 HP or pushed to 1,500+ HP for all-out racing.
What makes the VR38 truly special isn't just the raw numbers - it's the way Nissan engineered every detail to perfection. From the hand-built assembly to the plasma-coated bores to the dry-sump lubrication, every aspect serves a purpose. This is why GT-Rs continue to embarrass supercars costing twice as much at drag strips and road courses worldwide.
"The VR38 is proof that displacement isn't everything. Nissan took 3.8 liters and engineered it so well that it competes with engines twice its size. And when you start modifying it? The sky's the limit." - Josh Munford
At Raw Exotics, we have deep respect for the GT-R platform. Whether you're looking for a conservative tune to add 60 HP to your daily driver or planning a full race build chasing four-digit horsepower, we can help you achieve your goals safely and reliably. Stop by our Houston shop and let's discuss your GT-R project - these engines are capable of incredible things when properly built and tuned.
